The coil which is left on the loading car with forklift or crane is fast and safely attached to the drum with controller. The coil loading car moves in Z axis with hydraulic piston and in Y axis with ac motor drive. There are guide arms to prevent the loaded coil from falling over during the movement of the car.

Straightener feeder group opened from the inlet side with approximate 20-degree angle. This helps to introduce the sheet easily to the straightener group. This feature decreases the loss of time during the new coil loading. Opening of the group driven by hydraulic cylinders.

Feeder group height adjustment made automatically by a motorized system. When the sheet passage height from the bolster entered to the control panel, the feeder ascend or descend to entered height automatically.

Loading the coils on the drum as centered, operated by servo motorized lateral coil guides. When the operator inputs the sheet width on the operator panel, these side guides expand laterally from the center of the drum until the entered sheet width. By the way it prevenets the off center aligning of coil. Coil loading duration becomes faster and safer.

The guides at the inlet and outlet side of the straightener
and feeder group being adjusted by servo motors. When the operator enters the sheet width to the control panel, these guides moves laterally from the center and goes to reference point. This provides that the sheet reaches to die as centered into the straightener and feeder group. Servo motors allow to make this adjustment being completed in an accurate and very quick way.

Straightener top rolls group adjustment has been done by servo motors from inlet and outlet side. This control allows to make flatness adjustment more precisely. Position adjustment being made automatically which has been entered to control panel. Positions of the rolls can be monitored from control panel.

With the external encoder, feed sheet length controlled
another time. Feeding rolls measurement and encoder wheel
measurement controlled instantly during the feeding
operation. Possible slipping of the sheet durning the feeding
operation tolerated instantly.

Guillotine Shear, cuts sheet metal between feeder and die in
case of operation stop for any reason. Additionally, there are high speed and blade gap adjustment versions to make cut to length operations for transfer systems.
